1.17 U: Monitors
106 YASKAWA TOEPYAIGA5002A GA500 Programming
No.
(Hex.)
Name Description MFAO Signal Level
U8-31
(196E)
DWEZ Monitor 31
Shows DWEZ Monitor 31. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-32
(196F)
DWEZ Monitor 32
Shows DWEZ Monitor 32. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-33
(1970)
DWEZ Monitor 33
Shows DWEZ Monitor 33. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-34
(1971)
DWEZ Monitor 34
Shows DWEZ Monitor 34. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-35
(1972)
DWEZ Monitor 35
Shows DWEZ Monitor 35. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-36
(1973)
DWEZ Monitor 36
Shows DWEZ Monitor 36. (Display range: 0.00% to 999.99%)
Unit: 0.01%
10 V = 100%
U8-37
(1974)
DWEZ Monitor 37
Shows DWEZ Monitor 37. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-38
(1975)
DWEZ Monitor 38
Shows DWEZ Monitor 38. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-39
(1976)
DWEZ Monitor 39
Shows DWEZ Monitor 39. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-40
(1977)
DWEZ Monitor 40
Shows DWEZ Monitor 40.
No signal output available
U8-51
(1982)
DWEZ Monitor 51
Shows DWEZ Monitor 51. (Display range: -999.9% to +999.99%)
Unit: 0.01%
10 V = 100%
U8-52
(1983)
DWEZ Monitor 52
Shows DWEZ Monitor 52.
Unit: The number of decimal points shown is set with Q2-41.
10 V = 100%
U8-53
(1984)
DWEZ Monitor 53
Shows DWEZ Monitor 53.
Unit: The number of decimal points shown is set with Q2-42.
10 V = 100%
U8-54
(1985)
DWEZ Monitor 54
Shows DWEZ Monitor 54.
Unit: The number of decimal points shown is set with Q2-43.
10 V = 100%
U8-55
(1986)
DWEZ Monitor 55
Shows DWEZ Monitor 55.
Unit: The number of decimal points shown is set with Q2-44.
10 V = 100%
U8-60
(198B)
RemoteIO Status
Shows the operation status of Remote IO as 1 (ON) and 0 (OFF). If the DriveWorksEZ MEMOBUS
master active signal is ON, for example, the monitor shows U8-60 = 00000001.
bit 0 : Bit 0: DriveWorksEZ MEMOBUS Master Active
bit 1 : Not used (normal value of 0)
bit 2 : Not used (normal value of 0)
bit 3 : Not used (normal value of 0)
bit 4 : Not used (normal value of 0)
bit 5 : Not used (normal value of 0)
bit 6 : Not used (normal value of 0)
bit 7 : Not used (normal value of 0)
No signal output available
