Parameter List
1
1.7 d: Reference Settings
YASKAWA TOEPYAIGA5002A GA500 Programming 31
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d1-12
(028D)
RUN
Reference 12
Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection].
Note:
When A1-02 = 6 [Control Method Selection = AOLV/PM], the default setting is o1-03
= 1 [0.01% (100% = E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
231
d1-13
(028E)
RUN
Reference 13
Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection].
Note:
When A1-02 = 6 [Control Method Selection = AOLV/PM], the default setting is o1-03
= 1 [0.01% (100% = E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
231
d1-14
(028F)
RUN
Reference 14
Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection].
Note:
When A1-02 = 6 [Control Method Selection = AOLV/PM], the default setting is o1-03
= 1 [0.01% (100% = E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
231
d1-15
(0290)
RUN
Reference 15
Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection].
Note:
When A1-02 = 6 [Control Method Selection = AOLV/PM], the default setting is o1-03
= 1 [0.01% (100% = E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
231
d1-16
(0291)
RUN
Reference 16
Sets the frequency reference in the units from o1-03 [Frequency Display Unit Selection].
Note:
When A1-02 = 6 [Control Method Selection = AOLV/PM], the default setting is o1-03
= 1 [0.01% (100% = E1-04)].
0.00 Hz
(0.00 - 590.00 Hz)
232
d1-17
(0292)
RUN
Jog Reference
Sets the Jog frequency reference in the units from o1-03 [Frequency Display Unit
Selection]. Set H1-xx = 6 [MFDI Function Select = Jog Reference Selection] to use the
Jog frequency reference.
Note:
When A1-02 = 6 [Control Method Selection = AOLV/PM], the default setting is o1-03
= 1 [0.01% (100% = E1-04)].
6.00 Hz
(0.00 - 590.00 Hz)
232
◆ d2: Reference Limits
No.
(Hex.)
Name Description
Default
(Range)
Ref.
d2-01
(0289)
Frequency Reference
Upper Limit
Sets maximum limit for all frequency references. The maximum output frequency is 100%.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the maximum
output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Motor Max Revolutions]
100.0%
(0.0 - 110.0%)
232
d2-02
(028A)
Frequency Reference
Lower Limit
Sets minimum limit for all frequency references. The maximum output frequency is 100%.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the maximum
output frequency.
• A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Motor Max Revolutions]
0.0%
(0.0 - 110.0%)
233
d2-03
(0293)
Analog Frequency Ref
Lower Limit
Sets the lower limit for the master frequency reference (the first frequency of the multi-
step speed reference) as a percentage. The maximum output frequency is 100%.
Note:
Parameter A1-02 [Control Method Selection] selects which parameter is the maximum
output frequency.
• A1-02 ≠ 8: E1-04 [Maximum Output Frequency]
• A1-02 = 8: E9-02 [Maximum Speed]
0.0%
(0.0 - 110.0%)
233
