YASKAWA GA500 series - Yaskawa SSR1 Series IPM Motors (Derated Torque)

Parameter List
1
1.22 Parameters Changed by PM Motor Code Selection
YASKAWA TOEPYAIGA5002A GA500 Programming 129
No. Name Unit Motor Code (setting value of E5-01)
E5-05 PM Motor Resistance (ohms/phase) Ω
3.340 1.560 0.541
E5-06 PM d-axis Inductance (mH/phase) mH
6.58 3.82 2.24
E5-07 PM q-axis Inductance (mH/phase) mH
6.58 3.82 2.24
E5-09 PM Back-EMF Vpeak (mV/(rad/s)) mVs/rad
0.0 0.0 0.0
E5-24 PM Back-EMF L-L Vrms (mV/rpm) mV/min
-1
26.3 31.0 32.9
E1-04 Maximum Output Frequency Hz
180.0 180.0 180.0
E1-05 Maximum Output Voltage V
200.0 200.0 200.0
E1-06 Base Frequency Hz
180.0 180.0 180.0
E1-09 Minimum Output Frequency Hz
18.0 18.0 18.0
L3-24 Motor Accel Time @ Rated Torque s
0.100 0.100 0.100
n5-02 Motor Inertia Acceleration Time s
0.100 0.100 0.100
n8-49 Heavy Load Id Current %
0.0 0.0 0.0
◆ Yaskawa SSR1 Series IPM Motors (Derated Torque)
Table 1.9 SSR1 Series Motor Code Setting for Specification of 200 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Motor Code Selection - 1202 1203 1205 1206 1208 120A
Voltage Class V 200 200 200 200 200 200
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750
E5-02 PM Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03
PM Motor Rated Current
(FLA)
A 1.77 3.13 5.73 8.44 13.96 20.63
E5-04 PM Motor Pole Count - 6 6 6 6 6 6
E5-05
PM Motor Resistance (ohms/
phase)
Ω 8.233 2.284 1.470 0.827 0.455 0.246
E5-06
PM d-axis Inductance (mH/
phase)
mH 54.84 23.02 17.22 8.61 7.20 4.86
E5-07
PM q-axis Inductance (mH/
phase)
mH 64.10 29.89 20.41 13.50 10.02 7.43
E5-09
PM Back-EMF Vpeak (mV/
(rad/s))
mVs/rad 223.7 220.3 240.8 238.0 238.7 239.6
E5-24
PM Back-EMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Output Voltage V 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4
L3-24
*1
Motor Accel Time @ Rated
Torque
s 0.092 0.076 0.051 0.066 0.075 0.083
n5-02
Motor Inertia Acceleration
Time
s 0.092 0.076 0.051 0.066 0.075 0.083
n8-49 Heavy Load Id Current % -7.6 -11.5 -9.1 -19.0 -18.7 -23.4
*1 The default setting changes when the setting for o2-04 [Drive Model Selection] changes.
