YASKAWA GA500 series - Page 130

1.22 Parameters Changed by PM Motor Code Selection
130 YASKAWA TOEPYAIGA5002A GA500 Programming
Table 1.10 SSR1 Series Motor Code Setting for Specification of 200 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Motor Code Selection - 120B 120D 120E 120F 1210
Voltage Class V 200 200 200 200 200
Capacity kW 7.5 11 15 18.5 22
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750
E5-02 PM Motor Rated Power kW 7.5 11.0 15.00 18.50 22.00
E5-03 PM Motor Rated Current (FLA) A 28.13 41.4 55.4 68.2 80.6
E5-04 PM Motor Pole Count - 6 6 6 6 6
E5-05
PM Motor Resistance (ohms/
phase)
Ω 0.198 0.094 0.066 0.051 0.037
E5-06 PM d-axis Inductance (mH/phase) mH 4.15 3.40 2.45 2.18 1.71
E5-07 PM q-axis Inductance (mH/phase) mH 5.91 3.91 3.11 2.55 2.05
E5-09
PM Back-EMF Vpeak (mV/(rad/
s))
mVs/rad 258.2 239.3 248.1 253.6 250.0
E5-24
PM Back-EMF L-L Vrms (mV/
rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Output Voltage V 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum Output Frequency Hz 4.4 4.4 4.4 4.4 4.4
L3-24
*1
Motor Accel Time @ Rated
Torque
s 0.077 0.084 0.102 0.101 0.098
n5-02 Motor Inertia Acceleration Time s 0.077 0.084 0.102 0.101 0.098
n8-49 Heavy Load Id Current % -18.5 -10.9 -16.5 -11.3 -12.8
*1 The default setting changes when the setting for o2-04 [Drive Model Selection] changes.
Table 1.11 SSR1 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Motor Code Selection - 1232 1233 1235 1236 1238 123A
Voltage Class V 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750
E5-02 PM Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5
E5-03
PM Motor Rated Current
(FLA)
A 0.89 1.56 2.81 4.27 7.08 10.31
E5-04 PM Motor Pole Count - 6 6 6 6 6 6
E5-05
PM Motor Resistance (ohms/
phase)
Ω 25.370 9.136 6.010 3.297 1.798 0.982
E5-06
PM d-axis Inductance (mH/
phase)
mH 169.00 92.08 67.71 34.40 32.93 22.7
E5-07
PM q-axis Inductance (mH/
phase)
mH 197.50 119.56 81.71 54.00 37.70 26.80
E5-09
PM Back-EMF Vpeak (mV/
(rad/s))
mVs/rad 392.6 440.6 478.3 466.3 478.8 478.1
E5-24
PM Back-EMF L-L Vrms
(mV/rpm)
mV/min
-1
0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4
