5.1
DIN Rail Method
5.1.5
Replacing and Adding Option Modules
26
5.1.5
Replacing and Ad
ding Option Modules
Preparations
1.
T
urn OFF the MP23
iec Power Supply
2.
Remove the MP23
iec
Disconnect all cables from the
MP2300Siec. Then
remove the
MP2300Siec from the panel or ra
ck and place on a workbench or
other area with sufficient sp
ace.
Removing Option Modules
1.
Remove the battery cover
.
Pull the notch on th
e side of the MP23
iec towards you to
remove the battery cover
.
