YASKAWA MP2300Siec User Manual

14.1 AI-01 (Analog Input) Module
14.1.3 Module Specifications
52
14.1.3 Module Specifications
The following table shows the AI-01 Module hardware specifications.
14.1.4 LED Indicator
Item
Specifications
Classification I/O Module
Name AI-01
Model JAPMC-AN2300
Analog Input
Analog Input Range 10 to +10V
0 to +10V 0 to 20 mA
Number of Channels 8 ((4/ connector)×2)
Number of Channels to be Used Any number from 1 to 8
Isolation
Between channels: Not isolated.
Between input connector and system power supply:
Photocoupler isolation
Max. Rated Input 15V
30 mA
Input Impedance 20 k
250 k
Resolution 16-bit (31276 to +31276)
15-bit (0 to
+31276)
Absolute Accuracy 100 mV Max
0.3 mA Max
Accuracy
25°C 0.1% (10 mV)
0.1% (0.02 mA)
0 to 55°C 0.3% (30 mV)
0.3% (0.06 mA)
Input Conversion Time 1.4 msec Max
Connectors
CN1: Input connector
CN2: Input connector
LED Indicator RUN (green)
Current Consumption 500 mA Max
Dimensions 125×95 (H×D)
Mass 100 g
Indicator
Indicator
Color
Status when Lit Status when not Lit
RUN Green
Normal operation Operation stopped (no access from CPU)
