YASKAWA MP3300 series - Page 150

4.2 CPU Module Specifications
4.2.7 System Register Specifications
4-12
SW00104 to
SW00109
Reserved for system.
−
SW00110 to
SW00189
Detailed User Operation Error Status
 Detailed User Operation Error Status on page 4-
22
SW00190 to
SW00199
Reserved for system.
−
SW00200 to
SW00503
System I/O Error Status
 System I/O Error Status on page 4-23
SW00504 and
SW00505
Reserved for system. −
SW00506 and
SW00507
Security Status
 Security Status on page 4-23
SW00508 to
SW00649
Reserved for system. −
SW00650 to
SW00667
USB-related System Status
 USB-related System Status on page 4-24
SW00668 to
SW00693
Reserved for system.
−
SW00694 to
SW00697
Message Relaying Status
 Message Relaying Status on page 4-24
SW00698 to
SW00789
Interrupt Status
 Interrupt Status on page 4-25
SW00790 to
SW00799
Reserved for system.
−
SW00800 to
SW01095
Module Information
 Module Information on page 4-26
SW01096 to
SW01410
Reserved for system. −
SW01411 to
SW01442
MPU-01 Module Status
 MPU-01 Module Status on page 4-28
SW01443 to
SW02687
Reserved for system. −
SW02688 to
SW03199
PROFINET Controller (266IF-01) IOPS
Status
 PROFINET Controller (266IF-01) IOPS Status
Information on page 4-29
SW03200 to
SW05119
Motion Program Information
 Motion Program Execution Information on page
4-30
SW05120 to
SW05247
Used by the system (system memory
read).
−
SW05248 to
SW08191
Reserved for system. −
SW08192 to
SW09215
Expansion Motion Program Information
 Motion Program Execution Information on page
4-30
SW09216 to
SW09559
Reserved for system. −
SW09560 to
SW10627
Expansion System I/O Error Status
 Expansion System I/O Error Status on page 4-52
SW10628 to
SW13699
Reserved for system.
−
SW13700 to
SW14259
Expanded Unit and Module Information
 Expanded Unit and Module Information on page
4-53
SW14260 to
SW15997
Reserved for system. −
SW15998 to
SW16011
Expansion System Service Execution
Status
 Expansion System Service Execution Status on
page 4-54
SW16012 to
SW16199
Reserved for system. −
Continued on next page.
Continued from previous page.
Register
Address
Contents Details
