10.3 Pole Detection Functionality
10-5
10
SERVOPACK with Semi-closed Loop Control for Rotary Motors
After the function has been completed the motor power will turn OFF and the Servo Ready signal will turn
ON. Then the function cannot be executed even if the /P-DET signal is turned ON and OFF. Then the control
power is restored, the function must be executed again.
Utility Function: Pole Detection (Fn080)
This utility function is executed using Panel operator, Digital operator and SigmaWin+.
(3) Execution of the Function with MECHATROLINK and Network Option Model
Servo ON Command
Utility Function: Pole Detection (Fn080)
This utility function is executed using Panel operator, Digital operator and SigmaWin+.
(4) Related Parameters
Type Name Connector Pin No. Setting Description
Input
/S-ON
CN1-40
[Factory setting]
ON
Motor power is ON.
Motor will be ready for operation (/S-RDY signal is
ON).
OFF Motor power is OFF.
/P-DET Must be allocated
ON
The function is executed only once then the signal
turns ON for the first time.
OFF -
Type Name Description
Servo ON
Incremental Encoder
The function is executed only once when the command is sent. Then,
motor will be ready for operation.
Absolute Encoder
In the Pn587.0 = 1 setting, the function is executed only once when
the command is sent. Then, motor will be ready for operation.
Servo OFF Motor power is OFF.
Parameter
Function Default Value When enabled
No. Dig.
Pn481 Polarity Detection Speed Loop Gain [0.1 Hz] 40.0 Immediately
Pn482 Polarity Detection Speed Loop Integral Time [0.01 msec] 30.00 Immediately
Pn486 Polarity Detection Command Accel/Decel Time [msec] 25 Immediately
Pn487 Polarity Detection Constant Speed Time [msec] 0 Immediately
Pn488 Polarity Detection Command Waiting Time [msec] 100 Immediately
Pn490 Polarity Detection Load Level [%] 100 Immediately
Pn493
Polarity Detection Command Speed [min
-1
]
50 Immediately
Pn494 Polarity Detection Range [0.001 rev] 0.250 Immediately
Pn495 Polarity Detection Confirmation Torque Command [%] 100 Immediately
Pn498 Polarity Detection Allowable Error Range [deg.] 10 Immediately
Pn587 Polarity Detection for Absolute Scale Selection - -
0
0 Does not detect polarity
0 Immediately
1 Detects polarity
