User Constant Tables
5-29
H3-09 Settings
H3-09
Multi-function
analog input ter-
minal A2 func-
tion selection
Selects the multi-function analog
input function for terminal A2.
Refer to the table on the next
page.
0 to 16 0 No A 418H 6-22
H3-10
Gain (terminal
A2)
Sets the input level when terminal
A2 input is 10 V (20 mA) accord-
ing to the 100% value of the func-
tion set in constant H3-09.
0.0 to
1000.0
100.0% Yes A 419H 6-22
H3-11
Bias (terminal
A2)
Sets the input level when terminal
A2 is 0 V (4 mA/0 mA) according
to the 100% value of the function
set in constant H3-09.
-100.0
to
+100.0
0.0% Yes A 41AH 6-22
H3-12
Analog input filter
time constant
Sets primary delay filter time con-
stant for the two analog input ter-
minals (A1 and A2).
Effective for noise supression etc.
0.00 to
2.00
0.00
s
No A 41BH 6-22
H3-13
Terminal A1/A2
switching
0: Use terminal A1 analog input
as main frequency reference.
1: Use terminal A2 analog input
as main frequency reference.
Effective when H3-09 is set to 2.
0 or 1 0 No A 41CH –
Setting
Value
Function Contents (100%)
Page
0 Frequency bias Maximum output frequency 6-22
2
Auxiliary frequency reference (is used as
frequency reference 2)
Maximum output frequency 6-5
B PI feedback Maximum output frequency –
D Frequency Bias 2 Maximum output frequency 6-22
E Motor temperature input – 6-36
16 PI differential mode Maximum output frequency –
1F Analog input not used. – –
Constant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Access
Level
MEMO-
BUS
Register
Page
