Yealink VC110 - Call Protocol

Configuring Call Preferences
153
Video codecs parameters on the endpoint are described below:
Parameter
Description
Configuration Method
Enable Codecs
Specifies the enabled video codecs
for the endpoint to use.
Note: All support video codecs are
enabled on the endpoint by default.
Web User Interface
Disable Codecs
Specifies the disabled video codecs
for the endpoint not to use.
Web User Interface
To configure video codecs via web user interface:
1. Click on Account->Codec.
2. Select the desired video codec from the Disable Codecs or the Enable Codecs column.
3. Click or to disable or enable the selected video codec.
4. Select the desired video codec from the Enable Codecs column, and click or to
adjust the priority of the selected video codecs.
5. Click Confirm to accept the change.
Call Protocol
The endpoint supports SIP and H.323 protocols for incoming and outgoing calls. H.323 is
commonly used to communicate to other video conferencing endpoint. SIP is commonly used
