VC110 Video Conferencing Endpoint Introduction
9
VC110 All-in-one Unit
The VC110 all-in-one unit integrates the camera, the built-in microphone and the codec into a
unit. VC110 all-in-one unit compresses outgoing video and audio data, transmits this
information to the far end, and decompresses incoming data. It supports 16:9 and 4:3 aspect
ratios. It can be compatible with different audio output devices, and can adapt to the display
devices automatically.
Lens cover
The lens cover is used for protecting the lens, which shall not receive dust pollution and all
possible brush, collision.
The front of VC110 all-in-one unit
The HD camera supports 4xdigital zoom, white balance and automatic gain. You can place the
VC110 all-in-one unit on the table or mount it on a wall. The LED indicator in front of the camera
indicates different statuses of the endpoint. For more information, refer to LED Instructions on
page 36.
You can use the remote control to adjust the position or focus of the camera. The VC110 camera
can be panned (± 100 degrees range), tilted (± 30 degrees range).

Table of Contents

Other manuals for Yealink VC110

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Yealink VC110 and is the answer not in the manual?

Yealink VC110 Specifications

General IconGeneral
Digital zoom4 x
Focus adjustmentAuto
Video codecsH.264, H.263
Maximum frame rate30 fps
Supported video modes720p, 1080p
Video formats supportedH.263, H.264
Supported graphics resolutions352 x 288, 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Voice codecsG.711a, G.722, G.722.1, G.722.1C
Line-inYes
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pan range-100 - 100 °
Tilt angle range-30 - 30 °
Security algorithms128-bit AES, HTTPS, SRTP, SSL/TLS
Ethernet LAN data rates10, 100 Mbit/s
Supported network protocolsTCP/IP (IPv4), DHCP/ stastic IP, HTTP/ HTTPS, SRTP/TLS, IEEE802.1X, LLDP-MED, VLAN
Current2 A
Power consumption (max)30 W
Power consumption (typical)24 W
Storage temperature (T-T)-20 - 50 °C
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)10 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth151.5 mm
Width234.6 mm
Height161 mm
Package depth318 mm
Package width432 mm
Package height274 mm
Package weight5900 g
