Administrator’s Guide for Yealink VC110 Video Conferencing Endpoint
10
Infrared Sensor
The infrared sensor is located within the Yealink logo. Aim the remote control at the camera IR
sensor to operate the unit.
Note
The right side of the VC110 all-in-one unit
Inserts a USB flash drive to one of the two USB ports for
storing screenshots, recording videos or capturing packets.
Inserts a dongle to one of the two USB ports for connecting
the VCM60 video conferencing wireless microphone.
Note:
The wireless microphone dongle and USB flash drive
can work at the same time.
If two USB flash drives are connected, only the latter
one can be identified.
When the endpoint is powered on, avoid physically turning the camera. This may cause
permanent damage to the camera. Always use the remote control to pan and tilt it.
