VC110 Video Conferencing Endpoint Introduction
29
Muting or Unmuting the VCM30
There is a mute button at the top of the VCM30. You can mute or unmute it in the following
scenarios:
If you do not want to have your voice broadcast during a conference, you can tap the mute
button to mute the VCM30.
If you want to speak again during a conference, you can tap mute button to unmute the
VCM30.
To mute the VCM30 during a call:
1. Tap to mute the call.
The mute indicator LED illuminates solid red. And the mute icon appears on the local
video image.
To un-mute the VCM30 during a call:
1. Tap again to un-mute the call.
The mute indicator LED illuminates solid green. And the mute icon disappears from
the local video image.
Viewing VCM30 Information
When the VCM30 is connected to the Audio In port of cable hub, you can view VCM30 status via
the remote control or web user interface.
Available information of VCM30 includes:
Status
Model
Hardware Version
Serial Number
