Yealink VC110 - Page 63

Getting Started
47
2. Locate the Internet port on the cable hub, and connect it to the Internet port on the wall or
on the switch/hub device with the supplied 2m Ethernet cable.
Note
Power over Ethernet
With the included or a regular Ethernet cable, the VC110 video conferencing endpoint can be
powered from a PoE-compliant switch or hub.
To connect the PoE:
1. Locate the Internet port on the cable hub, and connect it to the port on the in-line power
switch/hub with the Ethernet cable.
Note
Remove power to power off the endpoint if long time no use.
If in-line power is provided, you don’t need to connect the cable hub to the power adapter. Make
sure the switch/hub is PoE-compliant.
Important! Do not remove power from the cable hub while it is updating firmware and
configurations.
The VC110 video conferencing endpoint should be used with Yealink original power adapter
(12V/2A) only.
