5-12
IM AQ1210-01EN
Turning the Event Position Fix Feature On and Off
Event positions can be fixed. Fixed events are handled as master events. You can configure the
Instrument so that in subsequent event analysis only master events are handled.
How the events that are detected at positions other than the master event positions are displayed
varies depending on the Event Fix Mode as follows:
When Event Fix Mode Is Set to Append Mode
Events detected at positions other than the master event positions are also displayed in the
event list.
Events other than fixed events are also detected.
An earlier event is detected, so
the number of this fixed event is
updated (changes from 3 to 4).
When Event Fix Mode Is Set to Master Mode
Only the events that are detected at the master event positions are displayed in the event list.
Not detected even when an event exists.
5.1 Analyzing in TRACE Mode
