1-27
IM AQ1210-01EN
Features
1
2
3
4
5
6
7
8
9
10
11
App
Index
Section Analysis
You can set two markers, start point S and end point E, to measure the return loss and total loss in
the section that you have specified. By setting reference point B, you can calculate the return loss
using the backscatter level you specify.
S E
B
1.7 Application
