Soft key menu
During averaged measurement
• When Averaged Measurement Is in Progress
Marker operation
See section 6.1.
Set comments.
See section 2.4.
Set labels.
See section 2.4.
• When Averaged Measurement Is Not in Progress
Marker operation
See section 6.1.
Event analysis control
See section 5.1.
Snapshot (Reference
trace) control
See section 6.3.
Section analysis control
See section 6.4.
Set work completion.
See section 3.3.
Moves the snapshot
waveform up
Moves the snapshot
waveform down
Displays the difference
waveform between the real-time
measurement waveform and
snapshot waveform
Switches the current trace
Can be controlled during multi
wavelength measurement.
Takes a snapshot
Clears the snapshot waveform
