YOKOGAWA CQ1 User Manual

<5. Functions of CQ1 Software> 5-5
IM 80J01A01-01E
5.2.2 Option Menu
(1) Channel Setting
Open Channel Setting window to set imaging channels. Please
refer to “5.9 Channel Setting” for details.
(2) Trimming Parameter
Open Trimming Parameter window i to change stitch parameter.
Please refer to “5.10 Trimming Parameter” for details.
(3) User Setting
Open User Setting window to change user setting. Please refer to
“5.11 User Setting” for details.
(4) Activation Setting
Open Activation Setting window to manage license of CQ1
Software. Please refer to “5.12 Activation Setting” for details.
CAUTION
Please do not operate Activation Setting window except when
necessary such as updating CQ1 Software. CQ1 Software might
be inoperatable. For updating CQ1 Software, please contact the
dealer.
