󳏃 Slide Ratio
Specify the travel distance when moving the imaging Field by
imaging Field shift button. Field size is a travel distance unit. For
example, by setting 0.10, the stage moves 1/10 of the Field size,
and setting 1.00 moves by one Field size.
󳏄 Color
Click this button to capture images at the current Field position at
all channels selected at “ImageViewer”.
󳏅 Z Mode
Select to run Z Stack imaging or not while preview imaging.
Z Mode
Description
Capture one image at the Center of Z Stack.
Capture “Slices” images at “StepHight” interval between
Top and Bottom of Z Stack.
󳏆 Add Field
Specify current imaging Field as the measurement location. The
measurement filed is shown in “Map” window of “Viewer”.
󳏇 Stop
Click this button to stop imaging which was started by either
mouse click of image Field or by clicking imaging Field shifting
button.
