5-26 <5. Functions of CQ1 Software>
IM 80J01A01-01E
Clear
Selection for Rec of all wells are canceled. This botton is displayed
when “Same Area” is checked.
PreRec
Start preliminary imaging of wells selected for Rec. You need to
select wells to be images by “Map” window beforehand.
Before performing object detects setting in “Analysis” window
(refer to 5.4.5 Analysis Window), preliminary imaging by this
button must have done.
Stop PreRec
Stop preliminary imaging.
(3) Field
Field selection
One well in the sample holder is shown here, within which location
of current Field is shown. By clicking within the well, XY stage
moves to the clicked point and capture an image, which will be
shown as preview at the “ImageViewer”.
XY coordinate
X-Y coordinate of current Field is shown for which the center of the
well is the point of origin. Field location can be shifted by inputting
values.
Imaging Field shift button
This button is to move imaging Field to the arrow direction. The
center “” button is to capture image at the current Field location
by channel selected in (1) Channels .
