<5. Functions of CQ1 Software> 5-25
IM 80J01A01-01E
(2) Wells
Selected sample vessel
Diagram of sample vessel selected at “Sample window” is shown.
Unselected wells are shown in white. Gray wells are unselectable
due to interference of objective lens.
By clicking white well when button is (white), the well is
selected for preview (red frame). By left-clicking or left-dragging
wells when button is (green), the wells are selected for
Rec (light blue). By right-clicking or right-dragging, selection for
Rec is canceled.
Same Area
Check here to capture images of the same Area in all wells of
microplate, slide. If unchecked, imaging Areas can be selected
individually for each well.
Select measurement area
Refer to above .
All Select
All wells are selected for Rec. This botton is displayed when
“Same Area” is checked.
Slide Glass Sample Holder
Red frame:
Selected for preview
Light blue:
Selected for Rec
