<5. Functions of CQ1 Software> 5-59
IM 80J01A01-01E
(5) Existence of Feature Data
If quantified data is included in measurement data, mark is
attached. Click mark to show pull down list of feature data. To
close this list, click anywhere outside of the list.
Quantified data selection check box
Check to select feature data. Plural selection is available.
Storage folder name of feature data.
Select re-quantify data
Re-quantify data means to review or repeat image analysis on
existing feature data. This button will be circle-marked when
selected.
Delete
Delete selected feature data, available when more than 2 boxes
are checked.
Read Viewer
Show the re-feature data (circled feature data) in “Viewer”,
available when re-feature data is selected.
