<5. Functions of CQ1 Software> 5-93
IM 80J01A01-01E
5.6.3 MAP Window
MAP viewer has (1) Test imaging mode, (2) Map mode, and (3) Rec
mode. Their common functions are shown in below.
Objective lens selection
Selected lens is highlighted.
Map clear
Clear the map in display.
Area List
Display Area list. If there is more than one Area, the leading
number of “Field” is shown.
Unimagable Region
Blue region in “Map” window can’t be designated as imaging
region because objective lens interferes with stage attachment,
sample holder and sample vessel.
To Next Page
