<5. Functions of CQ1 Software> 5-117
IM 80J01A01-01E
(2) Contrast Enhancement
Display intensity histograms of images of each channel, and Max. /Min,
intensity of displayed images.
Ch
Channel number
Merge Setting Button
Eye-mark shuts or opens by each click of this button.
Images of current channel are shown in “ImageViewer” when the
eye is open, and not shown if closed.
Intensity Display
Intensity information of displayed image is shown.
Intensity Range (Max./Min,)
Intensity distribution (Histogram)
Intensity range of displayed image (Intensity range setting
button)
Manual Contrast Range
Contrast range can be manually adjusted by unchecking [Auto].
Set the Min. contrast value
Set the Max. contrast value
