4-34 <4. Measurement Procedures>
IM 80J01A01-01E
In “Z stack” of “Imaging” window (refer to page 5-28), click “Search” to
search Z position which samples exist.
After Z position search, click “<<” to apply the result of searching to Z
Stack parameter.
In “Map” window, select “Map Mode” (refer to page 5-95) and select
sample searching region by mouse drug.
Click “Start” to start map imaging.
Apply the result of
searching to Z Stack
parameter.
Select “Map mode”
Drag the region for
searching
