<4. Measurement Procedures> 4-35
IM 80J01A01-01E
After map imaging, select “Test imaging mode” (refer to page 5-94),
change objective lens to that for measurement, and select suitable field
for measurement.
Note
Blue region in “Map” window can’t be designated as imaging region because
objective lens interferes with stage attachment, sample holder and sample
vessel.
Select “Test imaging mode”
Select suitable field for
measurement
Change objective lens
for that for
measurement.
