YOKOGAWA DL9040 User Manual

5-9
IM 701310-17E
Commands
1
2
3
4
5
6
App
Index
Command Function Page
:CURSor:MARKer:CM<x>:TRACe
Sets the source trace of the marker cursor or queries the current setting. 5-76
:CURSor:MARKer:CM<x>:V?
Queries all settings related to the voltage measurement of the marker cursor. 5-76
:CURSor:MARKer:CM<x>:V:STATe
Turns ON/OFF the voltage measurement of the maker cursor or queries the
current setting.
5-76
:CURSor:MARKer:CM<x>:V:VALue?
Queries the voltage value at the marker cursor position. 5-76
:CURSor:MARKer:FORM
Sets the marker cursor form or queries the current setting. 5-76
:CURSor:SERial?
Queries all settings related to the serial cursors. 5-76
:CURSor:SERial:SCURsor<x>?
Queries all settings related to the serial cursor. 5-76
:CURSor:SERial:SCURsor<x>:
ACTive
Sets the active level of the serial cursor or queries the current setting. 5-76
:CURSor:SERial:SCURsor<x>:
BCOunt
Sets the bit length of the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:
BITRate
Sets the bit rate of the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:
BITorder
Sets the bit order of the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:
FORMat
Sets the display format of the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:
HYSTeresis
Sets the hysteresis of the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:JUMP
Moves the serial cursor to the specified direction. 5-77
:CURSor:SERial:SCURsor<x>:LEVel
Sets the threshold level of the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:MODE
Turns ON/OFF the serial cursor or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:
POSition
Sets the serial cursor position or queries the current setting. 5-77
:CURSor:SERial:SCURsor<x>:TRACE
Sets the trace of the serial cursor or queries the current setting. 5-78
:CURSor:SERial:SCURsor<x>:TRACK
Jumps the serial cursor onto the zoom waveform. 5-78
:CURSor:SERial:SCURsor<x>:
VALue?
Queries the measured value of the serial cursor. 5-78
:CURSor:TYPE
Sets the cursor type or queries the current setting. 5-78
:CURSor:VERTical?
Queries all settings related to the vertical cursors. 5-78
:CURSor:VERTical:BASic?
Queries all settings related to basic items of the vertical cursors. 5-78
:CURSor:VERTical[:BASic]:ALL
Turns ON/OFF all basic items of the vertical cursors. 5-78
:CURSor:VERTical[:BASic]:DT?
Queries
allsettingsrelatedtothe∆Tmeasurementoftheverticalcursors.
5-78
:CURSor:VERTical[:BASic]:DT:
STATe
T
urnsON/OFFthe∆Tmeasurementoftheverticalcursorsorqueriesthe
current setting.
5-78
:CURSor:VERTical[:BASic]:DT:
VALue?
Queriesthe∆Tvalueoftheverticalcursors.
5-78
:CURSor:VERTical[:BASic]:
LINKag
e
Turns ON/OFF the vertical cursor link or queries the current setting. 5-78
:CURSor:VERTical[:BASic]:PERDt?
Queriesallsettingsrelatedtothe1/∆Tmeasurementoftheverticalcursors.
5-79
:CURSor:VERTical[:BASic]:PERDt:
STATe
T
urnsON/OFFthe1/∆Tmeasurementoftheverticalcursorsorqueriesthe
current setting.
5-79
:CURSor:VERTical[:BASic]:PERDt:
VALue?
Queriesthe1/∆Tvalueoftheverticalcursors.
5-79
:CURSor:VERTical[:BASic]:T<x>
?
Queries all settings related to the vertical cursor. 5-79
:CURSor:VERTical[:BASic]:T<x>:
JUMP
Jumps to the center position of the zoom waveform of the vertical cursor. 5-79
:CURSor:VERTical[:BASic]:T<x>:
POSition
Sets the vertical cursor position or queries the current setting. 5-79
:CURSor:VERTical[:BASic]:T<x>:
STATe
Turns ON/OFF the vertical cursor or queries the current setting. 5-79
:CURSor:VERTical[:BASic]:T<x>:
VALue?
Queries the time value at the vertical cursor. 5-79
:CURSor:VERTical:CALCulation?
Queries all settings related to calculation items of the vertical cursors. 5-79
:CURSor:VERTical:CALCulation:
ALL
Turns ON/OFF all calculation items of the vertical cursors. 5-79
:CURSor:VERTical:CALCulation:
DEFine<x>
Sets the equation of the calculation item of the vertical cursor or queries the
current setting.
5-80
:CURSor:VERTical:CALCulation:
STATe<x>
Turns ON/OFF the calculation item of the vertical cursor or queries the
current setting.
5-80
:CURSor:VERTical:CALCulation:
VALue<x>?
Queries the measured value of the calculation item of the vertical cursor. 5-80
5.1 List of Commands
