Command Function Page
XY Group
:XY<x>?
Queries all XY display settings. 5-286
:XY<x>:DISPlay
Sets or queries the on/off status of the XY display. 5-286
:XY<x>:MEASure?
Queries all automated measurement settings for the XY display. 5-286
:XY<x>:MEASure:CURSor?
Queries all cursor measurement settings for the XY display. 5-286
:XY<x>:MEASure:CURSor:DX?
Queries all settings for the voltage difference between the X-Y display's
horizontal cursors.
5-286
:XY<x>:MEASure:CURSor:DX:STATe
Sets or queries the on/off status of the voltage difference between the X-Y
display's horizontal cursors.
5-286
:XY<x>:MEASure:CURSor:DX:VALue?
Queries the voltage difference between the X-Y display's horizontal cursors. 5-286
:XY<x>:MEASure:CURSor:DY?
Queries all settings for the voltage difference between the X-Y display's
vertical cursors.
5-286
:XY<x>:MEASure:CURSor:DY:STATe
Sets or queries the on/off status of the voltage difference between the X-Y
display's vertical cursors.
5-286
:XY<x>:MEASure:CURSor:DY:VALue?
Queries the voltage difference between the X-Y display's vertical cursors. 5-286
:XY<x>:MEASure:CURSor:X<y>?
Queries all horizontal cursor settings for the XY display. 5-286
:XY<x>:MEASure:CURSor:X<y>:POSi
tion
Sets or queries a horizontal cursor position in the XY display. 5-287
:XY<x>:MEASure:CURSor:X<y>:STA
Te
Sets or queries the on/off status of the voltage of an X-Y display horizontal
cursor.
5-287
:XY<x>:MEASure:CURSor:X<y>:VAL
ue?
Queries the voltage of a horizontal cursor in the XY display. 5-287
:XY<x>:MEASure:CURSor:Y<y>?
Queries all vertical cursor settings for the XY display. 5-287
:XY<x>:MEASure:CURSor:Y<y>:POSi
tion
Sets or queries a vertical cursor position in the XY display. 5-287
:XY<x>:MEASure:CURSor:Y<y>:STA
Te
Sets or queries the on/off status of the voltage of an X-Y display vertical
cursor.
5-287
:XY<x>:MEASure:CURSor:Y<y>:VAL
ue?
Queries the voltage of a vertical cursor in the XY display. 5-287
:XY<x>:MEASure:INTeg?
Queries all integration settings for the XY display. 5-287
:XY<x>:MEASure:INTeg:LOOP
Sets or queries the integration method for the XY display. 5-287
:XY<x>:MEASure:INTeg:POLarity
Sets or queries the integration polarity for the XY display. 5-288
:XY<x>:MEASure:INTeg:VALue?
Queries the integrated value for the XY display. 5-288
:XY<x>:MEASure:MODE
Sets or queries the automated measurement mode for the XY display. 5-288
:XY<x>:SPLit
Sets or queries whether or not the XY display are split to XY1 and XY2
windows.
5-288
:XY<x>:TRANge (Time Range)
Sets or queries the range of T-Y waveform to display in the XY display. 5-288
:XY<x>:VTDisplay
Sets or queries the on/off status of the VT waveform display for the XY
display.
5-288
:XY<x>:XTRace
Sets or queries the channel that is assigned to the X-axis in the XY display. 5-288
:XY<x>:YTRace
Sets or queries the channel that is assigned to the Y-axis in the XY display. 5-288
ZOOM Group
:ZOOM<x>?
Queries all waveform zoom settings. 5-289
:ZOOM<x>:ALLocation?
Queries all zoom source waveform settings. 5-289
:ZOOM<x>:ALLocation:{CHANnel<y>
|MATH<y>}
Sets or queries the zoom source waveform. 5-289
:ZOOM<x>:DISPlay
Sets or queries the on/off status of a zoom waveform display. 5-289
:ZOOM<x>:FORMat
Sets or queries the format of a zoom waveform display. 5-289
:ZOOM<x>:MAG
Sets or queries the magnification of a zoom waveform display. 5-289
:ZOOM<x>:MAGFine
Sets or queries the magnification (Fine) of a zoom waveform display. 5-289
:ZOOM<x>:MAIN
Sets or queries the display ratio of a zoom waveform display. 5-289
:ZOOM<x>:POSition
Sets or queries the position of a zoom box. 5-289
:ZOOM<x>:VERTical?
Queries all vertical zoom settings. 5-289
:ZOOM<x>:VERTical:{CHANnel<y>|M
ATH<y>}?
Queries all of the settings of a trace for vertical zooming. 5-290
:ZOOM<x>:VERTical:{CHANnel<y>|M
ATH<y>}:MAG
Sets or queries the vertical zoom factor. 5-290
:ZOOM<x>:VERTical:{CHANnel<y>|M
ATH<y>}:POSition
Sets or queries the vertical zoom position. 5-290
:ZOOM<x>:VERTical:TRACe
Sets or queries the trace that is displayed in the vertical zoom window. 5-290
