5-40
IM DLM4038-17EN
Command Function Page
:SERialbus<x>:UART:SEARch:SETup
:DATA:ASCii
Sets the UART bus signal search data in ASCII format. 5-233
:SERialbus<x>:UART:SEARch:SETup
:DATA:CONDition
Sets or queries the data comparison condition (true or false) for UART signal
searching.
5-233
:SERialbus<x>:UART:SEARch:SETup
:DATA:CSENsitive
Sets or queries whether to distinguish uppercase and lowercase letters in
ASCII data for the UART bus signal search.
5-233
:SERialbus<x>:UART:SEARch:SETup
:DATA:DBYTe
Sets or queries the number of data bytes for UART signal searching. 5-234
:SERialbus<x>:UART:SEARch:SETup
:DATA:HEXa<y>
Sets the data for UART signal searching in hexadecimal notation. 5-234
:SERialbus<x>:UART:SEARch:SETup
:DATA:PATTern<y>
Sets or queries the data value for UART signal searching in binary notation. 5-234
:SERialbus<x>:UART:SEARch:SETup
:DATA:PFORmat
Sets or queries the data input format, which is one of the ID and data
conditions, for UART signal searching.
5-234
:SERialbus<x>:UART:SEARch:SETup
:ERRor?
Queries all UART signal search error settings. 5-234
:SERialbus<x>:UART:SEARch:SETup
:ERRor:FRAMing
Sets or queries the UART signal search framing error setting. 5-234
:SERialbus<x>:UART:SEARch:SETup
:ERRor:PARity
Sets or queries the UART signal search parity error setting. 5-234
:SERialbus<x>:UART:SEARch:SETup
:ERRor:PMODe
Sets or queries the UART signal search parity mode setting. 5-235
:SERialbus<x>:UART:SEARch:SETup
:FORMat
Sets or queries the format setting for UART signal analysis. 5-235
:SERialbus<x>:UART:SEARch:SETup
:MODE
Sets or queries the UART signal search mode. 5-235
:SERialbus<x>:ZLINkage
Sets or queries whether or not the analysis numbers of serial-bus signal-
analysis results are linked to zoom locations.
5-235
SNAP Group
:SNAP
Takes a snapshot. 5-236
SSTart Group
:SSTart?
Sets the trigger mode to SINGLE, and starts waveform acquisition. Returns
zero if data acquisition is stopped before the specified time period. Returns 1
if waveform acquisition is not stopped within the specified time period.
5-237
STARt Group
:STARt
Starts waveform acquisition. 5-238
STATus Group
:STATus?
Queries all of the settings for the communication status feature. 5-239
:STATus:CONDition?
Queries the contents of the condition register. 5-239
:STATus:EESE
Sets or queries the extended event enable register. 5-239
:STATus:EESR?
Queries the contents of the extended event register and clear the register. 5-239
:STATus:ERRor?
Queries the error code and message information (top of the error queue). 5-239
:STATus:FILTer<x>
Sets or queries the transition filter. 5-239
:STATus:QENable
Sets or queries whether or not messages other than errors will be stored to
the error queue (on/off).
5-239
:STATus:QMESsage
Sets or queries whether or not message information will be attached to the
response to the STATus:ERRor? query (on/off).
5-239
:STATus:SPOLl? (Serial Poll)
Executes serial polling. 5-239
STOP Group
:STOP
Stops waveform acquisition. 5-240
STORe Group
:STORe?
Queries all of the information related to setup data in the internal memory. 5-241
:STORe:SETup<x>?
Queries information about the setup data in the specified location of the
internal memory.
5-241
5.1 List of Commands
