YOKOGAWA GX20 User Manual

1-84
IM 04L51B01-01EN
MAX, MIN, P-P
Set how to handle overflow data when it is detected in the MAX, MIN, or P-P computation of
TLOG or CLOG. This setting is also applied to report generation.
Options Description
Over Computes by using the overflow data.
Skip Discards overflow data and continues the computation.
PSUMoverflowhandling
Setup Item Selectable Range or Options Default Value
Over/Rotate Rotate, Over Rotate
Over/Rotate
Set the handling of instances when the pulse integration result exceeds the displayable
range of the math channel.
Options Description
Rotate Minimum value: 0 When the value falls below the minimum value, continue
the computation by assuming the value of the next count
to be the maximum value.
Maximum value: 99999999 When the value exceeds the maximum value, continue
the computation by assuming the value of the next count
to be the minimum value.
Over Minimum value: -9999999 When the value falls below the minimum value, set the
result to overflow and stop the computation.
(Computed result: -OVER)
Maximum value: 99999999 When the value exceeds the maximum value, set the
result to overflow and stop the computation.
(Computed result: +OVER)
1.8.2 SettingExpressions
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Math channel settings >
Calculation expression
Web application: Config. tab > Math channel settings > Channel range (display example:
A001-A020) > Calculation expression
Hardware configurator: Math channel settings > Channelrange(displayexample:A001
toA020) > Calculation expression
Description
Setup Item Selectable Range or Options Default Value
First-CH GX20/GP20: A001 to A100
GX20-2/GP20-2: A001 to A200
1
GX10/GP10: A001 to A050
A001
Last-CH Same as the first channel A001
1 Release number 3 and later
First-CH, Last-CH
Set the target channels.
Math range
Setup Item Selectable Range or Options Default Value
On/Off Off, On Off
Calculation expression
1
Character string (up to 120 characters) 001
Decimal place
1
0, 1, 2, 3, 4, 5 2
Span Lower
1
–9999999 to 99999999 0.00
Span Upper
1
–9999999 to 99999999 100.00
Unit
1
Character string (up to 6 characters,
A
a
#
1
)
—
1 Appears when On/Off is set to On.
1.8ConfiguringMathChannels(/MToption)
