YOKOGAWA GX20 User Manual

1-234
IM 04L51B01-01EN
1.25.6 LoadingandDeletingProgramPatterns(/PGoption)(Releasenumber4
andlater),
Each program pattern is saved to a separate file.
Loading a Specified Pattern
Path
GX/GP: MENU key > Browse tab > Save load > Menu Load settings > Program pattern >
Load program pattern Load specified program pattern
Description
Setup Item Selectable Range or Options Default Value
Media Type SD/USB
1
Select file — —
Pattern name — —
Pattern number 1 to 99 1
File — —
1 See page 1-224 in section 1.25.1, “Loading Setting Parameters”.
Media type
Set the media.
Select file
Select a file.
Pattern name
The name of the selected pattern is displayed.
Pattern number
Set the pattern number to be loaded.
File
Displays the presence or absence of the specified pattern in the GX/GP.
Procedure
1 Tap Media type to select the medium.
2 Tap Select file to set the file.
3 Tap Pattern number to set the pattern number.
4 Tap Execute.
The selected pattern is loaded.
5 Tap Close.
The GX/GP returns to the original screen.
Operation complete
1.25 Loading Settings
