1-138
IM 04L51B01-01EN
1.13.2 SettingtheScanIntervalofEachModule
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Dual interval settings > Scan
interval > Module scan interval Main Unit or Unit 1 to 6 > Module0to9
1
Web application: Config. tab > Dual interval settings > Scan interval
Hardware configurator: Dual interval settings > Scan interval
1 The module numbers that appear depend on the GX/GP module configuration.
Description
Module0toModule9
Setup Item Selectable Range or Options Default Value
Measurement group number Measurement group 1, measurement group 2 —
Measurement group number
Set the scan group with the scan interval that you want the module to run at.
1.13.3 Setting the Recording Conditions
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Dual interval settings >
Recording settings
Web application: Config. tab > Dual interval settings > Recording settings
Hardware configurator: Dual interval settings > Recording settings
Description
Recording mode
Setup Item Selectable Range or Options Default Value
File type Event Event
File type
Event data is recorded (fixed).
Eventdata(Measurementgroup1)
Setup Item Selectable Range or Options Default Value
Recording interval 1ms, 2ms, 5ms, 10ms, 20ms, 50ms, 100ms,
200ms, 500ms, 1s, 2s, 5s, 10s, 15s, 20
s, 30s, 1min, 2min, 5min, 10min, 15min,
20min, 30
min
1s
Recording mode Free, Single, Repeat Free
Data length 2min, 5min, 10min, 20min, 30min, 1h, 2, h, 3h,
4h, 6h, 8h, 12h, 1day, 2day, 3day, 5day, 7day,
14day, 31day
1h
Recording interval
Set the event data recording interval. You cannot choose a recording interval that is shorter
than the scan interval.
Recording mode
Set the mode for recording event data.
Setup Item Description
Free Records data at all times
Single Records data when the trigger condition is met
Repeat Records data every time the trigger condition is met
1.13ConfiguringtheDualIntervalSettings(Releasenumber4andlater)
