1.23.11 SettingUSBInputDevices(/UHoption)
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu System settings > USB input
device
Web application: Config. tab > System settings > USB input device
Hardware configurator: System settings > USB input device
Description
Setup Item Selectable Range or Options Default Value
USB input device Japanese keyboard (109), US keyboard(104),
barcode reader
US keyboard(104)
USB input device
Set the type of keyboard to connect to the USB port.
If you are connecting a USB bar code reader, select the type that matches the specifications
of your bar code reader.
If you specify Bar-code reader, you will be able to execute communication commands
from the barcode reader. If you connect a keyboard, you can execute what you enter as
communication commands.
ExecutingCommunicationCommandswithaUSBBarcodeReader(Release
number2andlater)
ExecutableCommands
Group Command Description
Output FData Outputs the most recent channel data
FRelay Outputs the most recent relay (DO channel) and internal switch
status
Fstar Outputs the GX/GP status
FCtrlData Outputs control data
FCtrlMode Outputs the control mode
FCtrlNo Outputs the SP number and PID number
FPrgEnd Outputs the program control end signal status
FPrgEvent Outputs PV event and time event information
FPrgMode Outputs the program operation mode
FPrgPtnCur Outputs the currently running program pattern number and status
output
FPrgPtnInfo Outputs the program pattern information
Control ORec Starts or stops recording
OAlarmAck Clears alarm output (Alarm ACK)
OExecRec Manual trigger, manual sample, snapshot, timeout
OExecSNTP Queries the time using SNTP
OMessage Write messages
OMath Starts, stops, resets math or clears the computation dropout status
display
OSaveConf Saves setting data
OCommCh Sets a value to a communication channel
OEMail Starts or stops the e-mail transmission function
OMBRestore Recovers Modbus manually
ORTReset Resets a relative timer
OMTReset Reset a match time timer
OCmdRelay Outputs the DO channel and internal switch status
OBatName Sets a batch name
OBatComment Sets a batch comment
OBatText Sets a batch text
ODispRate Switches the trend interval
OLoadConf Loads setting data
OInit Clears measured data and initializes setting data
OUserLockACK User Locked ACK (for the advanced security function (/AS option))
OLoginAssist Assists login
Continued on next page
