1-189
IM 04L51B01-01EN
Configuring the GX/GP and Viewing the Settings
1
Query action
1
Setup Item Selectable Range or Options Default Value
Ref. time (Hour) 0 to 23 0
Ref. time (Minute) 0 to 59 0
Interval 6h, 12h, 24h 6 h
Timeout 10s, 30s, 90s 30s
Time adjust on Start action Off, On Off
1 Appears when the SNTP client function is set to On.
Ref.time(Hour),Ref.time(Minute)
Set the reference time for making queries.
Interval
Set the time interval for synchronizing the time with the server. The time is not synchronized
if the difference in the time between the GX/GP and the server is greater than equal to the
value specified in System settings > Time basic settings > Time deviation limit.
Timeout
Set the time to wait for the response from the SNTP server when querying the time.
Time adjust on Start action
Set this to On to synchronize the time using SNTP when recording is started.
When set to ON, the clock is adjusted when recording starts and when the GX/GP recovers
from power failures when recording is in progress.
1.21.6 ConfiguringtheModbusClientFunction(Option,Functionavailable
when/MCisspecified)
Configuring Basic Settings
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Communication(Ethernet)
settings > Modbus client settings > Basic settings
Web application: Config. tab > Communication(Ethernet)settings > Modbus client
settings
Hardware configurator: Communication(Ethernet)settings > Modbus client settings
Description
Modbus client function
Setup Item Selectable Range or Options Default Value
On/Off Off, On Off
On/Off
Select On to use the Modbus client function.
Communication
1
Setup Item Selectable Range or Options Default Value
Interval 100ms, 200ms, 500ms, 1s, 2s, 5s, 10s, 20s,
2
30s,
2
1 min
2
1 s
1 Appears when the Modbus client function is set to On.
2 Release number 2 and later.
Interval
Set the communication interval.
1.21ConfiguringtheEthernetCommunicationFunction
