YOKOGAWA GX20 User Manual

1-190
IM 04L51B01-01EN
Recovery action
1
Setup Item Selectable Range or Options Default Value
Wait time Off, 5s, 10s, 30s, 1min, 2min, 5min 2min
1 Appears when the Modbus client function is set to On.
Wait time
Set the interval for retrying the connection when the connection is interrupted for some
reason. Set this to Off to not retry connections.
If communication fails, communication stops.
Connection
1
Setup Item Selectable Range or Options Default Value
Keep connection Off, On Off
Connection timeout
2
1 to 10 (s) 1
1 Appears when the Modbus client function is set to On.
2 Appears when Keep connection is set to On.
Keep connection
Set this to On to maintain the connection with the external device.
Connection timeout
If you set Keep connection to On, set the duration to maintain the TCP connection with the
external Modbus device.
Explanation
Keep connection
Set whether to connect and disconnect TCP connections every time the GX/GP accesses an
external device.
If you set Keep connection to On, the TCP connection/disconnection procedure is skipped,
thereby reducing the amount of communication traffic between the devices.
However, some devices do not support this feature. Use this feature after you check the
specifications of the connected devices.
Even if Keep connection is set to OFF, if the communication interval is less than 1 s,
communication is performed as if Keep connection set to ON.
Configuring the Destination Server
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Communication(Ethernet)
settings > Modbus client settings > Modbus server settings
Web application: Config. tab > Communication(Ethernet)settings > Modbus server
settings
Hardware configurator: Communication(Ethernet)settings > Modbus server settings
Description
Setup Item Selectable Range or Options Default Value
Server number GX20-1/GP20-1: 1 to 16
GX20-2/GP20-2: 1 to 32
GX10/GP10: 1 to 16
1
Server number
Set the registration number of the server.
1.21ConfiguringtheEthernetCommunicationFunction
