YOKOGAWA GX20 User Manual

1-152
IM 04L51B01-01EN
Depending on the kind of report, set the items with check marks in the table below.
Setup Item
Kind
Hourly + Daily Daily + Weekly Daily + Monthly Batch Daily custom
Day

Day of week
 
Hour
   
Minute

Save interval
 
File creation interval

Day,Dayofweek,Hour,Minute
Set the day or day of week and the time to create reports.
Saveinterval(forBatchandDaycustom)
Set the data recording interval.
Filecreationinterval(forDaycustom)
Set the time interval for dividing files.
Data type
Setup Item Selectable Range or Options Default Value
Report 1 to 5 Ave, Max, Min, Sum, Inst —
Report 1 to 5
Set the data type to output as reports.
Options Description
Ave Outputs average values.
Max Outputs maximum values.
Min Outputs minimum values.
Sum Outputs sum values.
Inst Outputs instantaneous values.
File type
1
Setup Item Selectable Range or Options Default Value
File type Separate/Combine Combine
1 Appears when the Type is not set to Batch or Daily custom.
File type
Set this item when creating two types of reports such as daily report and monthly report.
Options Description
Separate
Saves each type of report to a separate file.
For information about
how files are divided, see page 1-143 in section 1.14.2, “Setting the
Save Method to Media (Auto save or manual save) and Media FIFO”.
Combine Saves the report data of two types in a single file.
Report template output
Setup Item Selectable Range or Options Default Value
Excel file Off, On Off
PDF file Off, On Off
Printer Off, On Off
Excelfile
Set this to On to output in Excel format.
1.16ConfiguringtheReportFunction(/MToption)
