1-254
IM 04L51B01-01EN
Procedure
1 Press MENU.
The menu screen appears.
2 Tap Browse tab > Init/Calib > menu Initialize > Individual settings.
The menu screen appears.
3 To initialize display group settings, tap Display group settings and then On.
Otherwise, tap Off.
4 To initialize recording channel settings, tap Recording channel settings and then On.
Otherwise, tap Off.
5 Tap Execute.
A conrmation screen is displayed.
6 Tap OK.
The settings are initialized.
Operation complete
1.29.3 Setting the Measurement Mode
The measurement mode determines how the entire GX/GP system operates. The GX/
GP measurement characteristics change depending on the measurement mode. The
measurement mode must be set before reconfiguration and before specifying various
settings.
Depending on the measurement mode, there are limits to the modules that can be used, the
number of measurement channels and recording channels, and so on. For details, see the
following general specifications.
General Specifications Name General Specifications No.
GX/10/GX20 Paperless Recorder (panel mount type) GS 04L51B01-01EN
GP10/GP20 Paperless Recorder (portable type) GS 04L52B01-01EN
Path
GX/GP: MENU key > Browse tab > Init/Calib > menu Measurement mode
Description
Setup Item Selectable Range or Options Default Value
Measurement mode Normal, High speed, Dual interval Normal
Measurement mode
Set the measurement mode according to the measurement conditions.
Options Description
Normal Data collection (measurement and recording) can be performed at 100 ms minimum.
High speed Data collection (measurement and recording) can be performed at 1 ms minimum.
Dual interval Data collection (measurement and recording) can be performed at two different scan
intervals.
Procedure
1 Tap Measurement mode.
The available measurement modes are displayed.
2 Set the measurement mode, and tap Execute.
A conrmation screen is displayed.
3 Tap OK.
The measurement mode is changed.
Operation complete
1.29InitializingandCalibratingtheSystem(Initialization,reconfiguration,touchscreencalibration),SettingtheMeasurementMode
