1.16 ConfiguringtheReportFunction(/MToption)
Set the report function.
When the measurement mode is set to High speed or Dual interval, there is a limit to the
number of report channels at scan intervals shorter than 100 ms. For details, see the
following general specifications.
GX/10/GX20 Paperless Recorder (panel mount type) GS 04L51B01-01EN
GP10/GP20 Paperless Recorder (portable type) GS 04L52B01-01EN
1.16.1 SettingtheReportType,CreationTime,DataType,Etc.
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Report settings > Basic
settings
Web application: Config. tab > Report settings > Report basic settings
Hardware configurator: Report settings > Report basic settings
Description
Type
Setup Item Selectable Range or Options Default Value
Type Off, Hourly + Daily, Daily + Weekly, Daily +
Monthly, Batch, Daily custom
Off
Type
Set the kind of report to create.
Options Description
Off Disables the report function.
Hourly + Daily Creates hourly and daily reports.
Hourly report: Creates report data every hour on the hour for the previous one
hour.
Daily report: Creates report data every day at a specified time for the previous
one day.
Daily + Weekly Creates hourly and weekly reports.
Weekly report: Creates report data every week at a specified time at a
specified day of the week for the previous one week.
Daily + Monthly Monthly report: Creates report data every month at a specified time at a
specified day for the previous one month.
Batch Creates a report in unit of batches.
Daily custom Creates daily reports by dividing it at the specified time intervals.
Creation time
1
Setup Item Selectable Range or Options Default Value
Day 1 to 28 1
Day of week Sunday, Monday, Tuesday, Wednesday,
Thursday, Friday, Saturday
Sunday
Hour 0 to 23 0
Minute 0 to 59 0
Save interval
2
2min, 3min, 4min, 5min, 10min, 15min, 30min, 1h 10min
File creation interval 4h, 6h, 8h, 12h, 24h 4h
1 Appears when the kind of report is not set to Off.
2 Appears when the type is set to Batch or Daily custom.
