YOKOGAWA GX20 User Manual

3-71
IM 04L51B01-01EN
Using Network Functions (Ethernet interface)
1
2
3
4
5
App
Index
3.3 Accessing the Measurement Data File on the
GX/GPfromaPC(FTPserverfunction)
You can use a PC to access the GX/GP via FTP. You can perform operations such as
retrieving directory and file lists from the external storage medium (SD memory card) of the
GX/GP and transferring and deleting files. In addition, you can also retrieve the directory or
file list and transfer files in the internal memory.
Files stored on the external storage medium
PC
FTP server
Ethernet
GX/GP
3.3.1 Configuring FTP Server Settings
Description
• EnabletheFTPserverfunction
• SettheFTPserverdirectoryoutputformat
For details on the settings, see page 1-194 in section 1.21.9, “Setting the Server Functions
to Use (FTP, HTTP, SNTP, MODBUS, GENE, DARWIN compatible communication)”.
3.3.2 Accessing the GX/GP from a PC
When Not Using the Login Function
Access the GX/GP from a PC via FTP using the admin, user, or anonymous account.
With the admin account, you can
• Retrieve directory and file lists from the external storage medium and transfer and delete
directories and files on the external storage medium.
• Retrieve directory and file lists from the internal memory and transfer directories and files
in the internal memory.
With the user or anonymous account, you can
• Retrieve directory and file lists from the external storage medium.
