YOKOGAWA GX20 User Manual

1-134
IM 04L51B01-01EN
Note
When the measurement mode is set to Normal
• The maximum number of channels that the GX20/GP20 can record varies depending on the
recording interval and file type (for the GX20-2/GP20-2).
Display data
Recording Interval
(Unit:/div)
GX20-1/GP20-1 GX20-2/GP20-2
Display Display+Event Display Display+Event
5s 100ch 100ch 200ch 100ch
10s 200ch 200ch 500ch 200ch
15s 500ch 500ch 1000ch 500ch
30s or more 500ch 500ch 1000ch 1000ch
Event data
Recording Interval GX20-1/GP20-1 GX20-2/GP20-2
Event Display+Event Event Event+Display
100ms 100ch 100ch 500ch 100ch
200ms 200ch 200ch 500ch 200ch
500ms 500ch 500ch 1000ch 500ch
1s or more 500ch 500ch 1000ch 1000ch
• The GX10/GP10 can record up to 100 channels regardless of the recording interval or file type.
When the measurement mode is set to High speed or Dual interval
There is a limit to the number of channels that can record at recording intervals shorter than 100
ms.
For the limitations, see the limitations provided in the following general specifications.
GX/10/GX20 Paperless Recorder (panel mount type) GS 04L51B01-01EN
GP10/GP20 Paperless Recorder (portable type) GS 04L52B01-01EN
1.12SettingRecordingConditions(Recordingmode,recordinginterval,savinginterval)
