Explanation
Resetting a Relative Timer
Resets a timer and starts it.
If you reset a relative timer, it is considered to have expired (if the timer is being used as an
event, the corresponding action is executed).
Resetting a Match Time Timer
Resets a match time timer after it expires so that it is enabled again.
• Resetting a match time timer is not considered a timeout (even if it is being used as an
event in the event action function, the corresponding action is not executed).
• This operation can be used with match time timers whose timer action is set to single.
Loading Setting Parameters
This action can be specified only when the event is set to remote control input.
This action loads a setup data file from the root directory of the SD memory card and
configures the GX/GP accordingly. Setup data files are named “LOAD1.GNL,” “LOAD2.
GNL,” and so on up to “LOAD10.GNL.” If the advanced security function is enabled, the
extension is .GSL.
You must create a setting parameter file and save it to the SD memory card in advance.
If the advanced security function (/AS option) is in use, security settings are not loaded.
Time Adjustment
Time adjustment can be specified as an action only when the event is set to remote control
input. This action sets the GX/GP internal clock to the nearest hour.
• OperationWhenRecordingIsStopped
Difference from the Nearest
Hour
Operation
00 min 00 s to 01 min to 59 s Truncates the minutes and seconds.
Example: 10 hours 01 min 50 s becomes 10 hours 00 min 00 s.
02 min 00 s to 57 min to 59 s The time is not changed.
58 min 00 s to 59 min to 59 s Rounds up the minutes and seconds.
Example: 10 hours 59 min 50 s becomes 11 hours 00 min 00 s.
• OperationduringRecording
If the time difference between the event occurrence time and the nearest hour is within
the time specified by Gradually adjusting the time of Time basic settings, the time
is gradually corrected. Otherwise, the time is corrected according to Time adjustment
beyond limit.
See the explanation in page 1-205 in section 1.23.4, “Setting the Time Zone, Gradual
Time Adjustment, and Daylight Saving Time”.
InternalSwitchesandRelayOutputforScanIntervalsShorterThan100ms
Internal switches and relays triggered by event actions are output at 100 ms intervals.
1.19ConfiguringtheEventActionFunction
