Setting the DO Channel Type
• SetupScreen
MENU key > Browse tab > Setting > Setting menu DO channel settings > Range
• SetupItems
Setup Item Value
First-CH/Last-CH 009
Range Type Manual
ConfiguringtheEventAction
• Procedure
MENU key > Browse tab > Setting > Setting menu Eventaction
• SetupItems
Setup Item Value
Event action number 4
Event action On/Off On
Event Type Status
Detail Record
Operation mode Rising edge
Action Type Relay
No. 0009
Detail Off
Setup Item Value
Event action number 5
Event action On/Off On
Event Type Status
Detail Record
Operation mode Falling edge
Action Type Relay
No. 0009
Detail On
1.19ConfiguringtheEventActionFunction
