Terminators
The following input is considered a terminator. The barcode entered up to the terminator is
executed as a communication command.
Terminator Notes
ENTER key You cannot create a barcode for the ENTER key. Set it as a footer
or suffix on the USB barcode reader.
Barcode “/////” —
Input Conditions
• The codes that can be input are uppercase and lowercase alphabet characters, numbers,
symbols, spaces, and returns.
• The barcode character type that the GX/GP can read is ASCII characters (numbers,
symbols, and uppercase and lowercase alphabet characters).
• The longest barcode that can be input is 200 characters excluding the terminator.
• If an invalid character is input, it is not executed.
• Passwords (input displayed with asterisks) cannot be set or input.
CommandsThatCanBeExecutedDependingonTouch-OperationSecurity
Settings
Depending on the touch-operation security settings and login status, the following
communication commands can be executed.
Group Command No Security With Security
No Logged-in User With Logged-in User
Output FData
  
FRelay
  
Fstar
  
FCtrlata
  
FCtrlMode
  
FCtrlNo
  
FPrgEnd
  
FPrgEvent
  
FPrgMode
  
FPrgPtnCur
  
FPrgPtnInfo

1

Control Orec

1

OAlarmAck

1

OExecRec

1

OExecSNTP

1

OMessage

1

OMath

1

OSaveConf

1

OCommCh
  
OEMail

1

OMBRestore

1

ORTReset

1

OMTReset

1

OCmdRelay

1

OBatName

1

OBatComment

1

OBatText

1

ODispRate

1

OLoadConf

1

OInit

1

OUserLockACK

1

OLoginAssist 2

3
OSendValue
  
OTransChAO

1

OTransAllAO

1

OCmdAO

1

OSLMPRestore

1

OSaveConfAll

1

OLoadConfAll

1

Continued on next page
