YOKOGAWA GX20

3-58
IM 04L51B01-01EN
Save all
1 Select the Data tab > Save/Load > Filelist(Saveall/Loadall).
A File list screen appears.
2 Click Save all settings.
A Save all settings dialog box opens.
3 Enter the folder name in the Folder Name text box.
4 Click OK.
All the les are saved.
Setting parameters, scale images, report templates, trusted certicates, server certicates, and
custom displays are saved.
Load all
1 Select the Data tab > Save/Load > Filelist(Saveall/Loadall).
A File list screen appears.
2 Select the folder you save using Save all settings to open it.
3 Click Load all settings.
A Load all settings dialog box opens.
4 Click OK.
All the les are loaded.
Setting parameters, scale images, report templates, trusted certicates, and custom displays are
loaded.
3.1 Using the Web Application to Change the GX/GP Settings, Monitor Data, and Control the GX/GP (Web server function)
