YOKOGAWA GX20 User Manual

1-28
IM 04L51B01-01EN
Note
For the channels in which you are not using an electromagnetic relay type module, set the range
type to Skip.
Range
Set the input type range.
Range Details
Type Range Selectable Range Default Value Notes
Volt
(DC voltage)
20mV –20.000 mV to 20.000 mV 2V
60mV –60.00 mV to 60.00 mV
200mV –200.00 mV to 200.00 mV
1V –1.0000 V to 1.0000 V
2V –2.0000 V to 2.0000 V
6V –6.000 V to 6.000 V
20V –20.000 V to 20.000 V
50V –50.00 V to 50.00 V
100V –100.00V to 100.00V For the high-speed
universal type
DI LVL (level) On (1)/off (0) (voltage) LVL On: 2.5 V or higher
Off: 2.3 V or less
DI (contact) On (1)/off (0) (contact)
GS
(general signal)
0.4-2V 0.3200 V to 2.0800 V 1 - 5 V
1-5V 0.800 V to 5.200 V
DC current
(0 to 20 mA)
— 0.000 mA to 20.000 mA —
GS
(4 to 20 mA)
— 3.200 mA to 20.800 mA —
TC
(thermocouple)
R 0.0 to 1760.0°C K Type R
S 0.0 to 1760.0°C Type S
B 0.0 to 1820.0°C Type B
K –270.0 to 1370.0°C Type K
K-H –200.0 to 500.0°C Type K (high precision)
E –270.0 to 800.0°C Type E
J –200.0 to 1100.0°C Type J
T –270.0 to 400.0°C Type T
N –270.0 to 1300.0°C Type N
W 0.0 to 2315.0°C Type W
L –200.0 to 900.0°C Type L
U –200.0 to 400.0°C Type U
WRe3-25 0.0 to 2320.0°C Type WRe (WRe3-25)
PLATINEL 0.0 to 1395.0°C
PR20-40 0.0 to 1900.0°C
KpvsAu7Fe 0.0 to 300.0K Kp vs Au7Fe
NiNiMo 0.0 to 1310.0°C
WWRe26 0.0 to 2320.0°C W/WRe26
N14 0.0 to 1300.0°C Type N(AWG14)
XK –200.0 to 600.0°C XK GOST
RTD
(resistance
temperature
detector)
Pt100 –200.0 to 850.0°C Pt100
Pt100-H –150.00 to 150.00°C Pt100 (high resolution)
JPt100 –200.0 to 550.0°C
JPt100-H –150.00 to 150.00°C JPt100 (high resolution)
Cu10GE –200.0 to 300.0°C Cu10(GE)
Cu10LN –200.0 to 300.0°C Cu10 (L&N)
Cu10WEED –200.0 to 300.0°C Cu10 (WEED)
Cu10BAILEY –200.0 to 300.0°C Cu10 (BAILEY)
Cu10a392 –200.0 to 300.0°C Cu10: α = 0.00392 at 20°C
Cu10a393 –200.0 to 300.0°C Cu10: α = 0.00393 at 20°C
Cu25 –200.0 to 300.0°C Cu25: α = 0.00425 at 0°C
Cu53 –50.0 to 150.0°C Cu53: α = 0.00426035 at 0°C
Cu100 –50.0 to 150.0°C Cu100: α = 0.00425 at 0°C
J263B 0.0 to 300.0K J263*B
Ni100SAMA –200.0 to 250.0°C Ni100(SAMA)
Ni100DIN –60.0 to 180.0°C Ni100(DIN)
Ni120 –70.0 to 200.0°C
Pt25 –200.0 to 550.0°C
Continued on next page
1.2ConfiguringAIChannels(Analog(includingDI)input)channelsandAI(mA)channels
