YOKOGAWA GX20 User Manual

4-20
IM 04L51B01-01EN
Unit I/O Channel Data Input Register Data Type
• Register
Channel 0001 example
Higher bytes Lower bytes
Register 300002
Channel 0001 data
Register 300001
• There is no decimal place information.
• 32-bitfloatingpoint
Unit I/O Channel Data Input Register Data Type
GX/GP main unit Lower bytes of the channel 0001 data 301001 32-bit floating point
Higher bytes of the channel 0001 data 301002
| |
Lower bytes of the channel 0050 data 301099
Higher bytes of the channel 0050 data 301100
Lower bytes of the channel 0101 data 301101
Higher bytes of the channel 0101 data 301102
| |
Lower bytes of the channel 0150 data 301199
Higher bytes of the channel 0150 data 301200
Lower bytes of the channel 0201 data 301201
Higher bytes of the channel 0201 data 301202
| |
Lower bytes of the channel 0250 data 301299
Higher bytes of the channel 0250 data 301300
Lower bytes of the channel 0301 data 301301
Higher bytes of the channel 0301 data 301302
| |
Lower bytes of the channel 0350 data 301399
Higher bytes of the channel 0350 data 301400
Lower bytes of the channel 0401 data 301401
Higher bytes of the channel 0401 data 301402
| |
Lower bytes of the channel 0450 data 301499
Higher bytes of the channel 0450 data 301500
Lower bytes of the channel 0501 data 301501
Higher bytes of the channel 0501 data 301502
| |
Lower bytes of the channel 0550 data 301599
Higher bytes of the channel 0550 data 301600
Lower bytes of the channel 0601 data 301601
Higher bytes of the channel 0601 data 301602
| |
Lower bytes of the channel 0650 data 301699
Higher bytes of the channel 0650 data 301700
Lower bytes of the channel 0701 data 301701
Higher bytes of the channel 0701 data 301702
| |
Lower bytes of the channel 0750 data 301799
Higher bytes of the channel 0750 data 301800
Lower bytes of the channel 0801 data 301801
Higher bytes of the channel 0801 data 301802
| |
Lower bytes of the channel 0850 data 301899
Higher bytes of the channel 0850 data 301900
Lower bytes of the channel 0901 data 301901
Higher bytes of the channel 0901 data 301902
| |
Lower bytes of the channel 0950 data 301999
Higher bytes of the channel 0950 data 302000
Continued on next page
4.5 Modbus Function and Register Assignments
