YOKOGAWA GX20 User Manual

4-40
IM 04L51B01-01EN
Unit I/O Channel Data Hold Register Data Type
Expandable I/O 5 Lower bytes of the channel 5001 data 430001 32-bit signed integer
Higher bytes of the channel 5001 data 430002
| |
Lower bytes of the channel 5050 data 430099
Higher bytes of the channel 5050 data 430100
Lower bytes of the channel 5101 data 430101
Higher bytes of the channel 5101 data 430102
| |
Lower bytes of the channel 5150 data 430199
Higher bytes of the channel 5150 data 430200
Lower bytes of the channel 5201 data 430201
Higher bytes of the channel 5201 data 430202
| |
Lower bytes of the channel 5250 data 430299
Higher bytes of the channel 5250 data 430300
Lower bytes of the channel 5301 data 430301
Higher bytes of the channel 5301 data 430302
| |
Lower bytes of the channel 5350 data 430399
Higher bytes of the channel 5350 data 430400
Lower bytes of the channel 5401 data 430401
Higher bytes of the channel 5401 data 430402
| |
Lower bytes of the channel 5450 data 430499
Higher bytes of the channel 5450 data 430500
Lower bytes of the channel 5501 data 430501
Higher bytes of the channel 5501 data 430502
| |
Lower bytes of the channel 5550 data 430599
Higher bytes of the channel 5550 data 430600
Expandable I/O 6 Lower bytes of the channel 6001 data 435001
Higher bytes of the channel 6001 data 435002
| |
Lower bytes of the channel 6050 data 435099
Higher bytes of the channel 6050 data 435100
Lower bytes of the channel 6101 data 435101
Higher bytes of the channel 6101 data 435102
| |
Lower bytes of the channel 6150 data 435199
Higher bytes of the channel 6150 data 435200
Lower bytes of the channel 6201 data 435201
Higher bytes of the channel 6201 data 435202
| |
Lower bytes of the channel 6250 data 435299
Higher bytes of the channel 6250 data 435300
Lower bytes of the channel 6301 data 435301
Higher bytes of the channel 6301 data 435302
| |
Lower bytes of the channel 6350 data 435399
Higher bytes of the channel 6350 data 435400
Lower bytes of the channel 6401 data 435401
Higher bytes of the channel 6401 data 435402
| |
Lower bytes of the channel 6450 data 435499
Higher bytes of the channel 6450 data 435500
Lower bytes of the channel 6501 data 435501
Higher bytes of the channel 6501 data 435502
| |
Lower bytes of the channel 6550 data 435599
Higher bytes of the channel 6550 data 435600
Continued on next page
4.5 Modbus Function and Register Assignments
