YOKOGAWA GX20 User Manual

4-46
IM 04L51B01-01EN
• 16-bitSignedInteger
Unit I/O Channel Data Hold Register Data Type
GX/GP main unit Channel 0001 data 402001 16-bit signed integer
| |
Channel 0050 data 402050
Channel 0101 data 402051
| |
Channel 0150 data 402100
Channel 0201 data 402101
| |
Channel 0250 data 402150
Channel 0301 data 402151
| |
Channel 0350 data 402200
Channel 0401 data 402201
| |
Channel 0450 data 402250
Channel 0501 data 402251
| |
Channel 0550 data 402300
Channel 0601 data 402301
| |
Channel 0650 data 402350
Channel 0701 data 402351
| |
Channel 0750 data 402400
Channel 0801 data 402401
| |
Channel 0850 data 402450
Channel 0901 data 402451
| |
Channel 0950 data 402500
Expandable I/O 1 Channel 1001 data 412001
| |
Channel 1050 data 412050
Channel 1101 data 412051
| |
Channel 1150 data 412100
Channel 1201 data 412101
| |
Channel 1250 data 412150
Channel 1301 data 412151
| |
Channel 1350 data 412200
Channel 1401 data 412201
| |
Channel 1450 data 412250
Channel 1501 data 412251
| |
Channel 1550 data 412300
Expandable I/O 2 Channel 2001 data 417001
| |
Channel 2050 data 417050
Channel 2101 data 417051
| |
Channel 2150 data 417100
Channel 2201 data 417101
| |
Channel 2250 data 417150
Channel 2301 data 417151
| |
Channel 2350 data 417200
Channel 2401 data 417201
| |
Channel 2450 data 417250
Expandable I/O Channel 2501 data 417251
| |
Channel 2550 data 417300
Continued on next page
4.5 Modbus Function and Register Assignments
