4-52
IM 04L51B01-01EN
• 32-bitfloatingpoint
I/O Channel Data Hold Register Data Type
Lower bytes of the channel 0001 data 404201 32-bit floating point
Higher bytes of the channel 0001 data 404202
| |
Lower bytes of the channel 0010 data 404219
Higher bytes of the channel 0010 data 404220
Lower bytes of the channel 0101 data 404221
Higher bytes of the channel 0101 data 404222
| |
Lower bytes of the channel 0110 data 404239
Higher bytes of the channel 0110 data 404240
Lower bytes of the channel 0201 data 404241
Higher bytes of the channel 0201 data 404242
| |
Lower bytes of the channel 0210 data 404259
Higher bytes of the channel 0210 data 404260
Lower bytes of the channel 0301 data 404261
Higher bytes of the channel 0301 data 404262
| |
Lower bytes of the channel 0310 data 404279
Higher bytes of the channel 0310 data 404280
Lower bytes of the channel 0401 data 404281
Higher bytes of the channel 0401 data 404282
| |
Lower bytes of the channel 0410 data 404299
Higher bytes of the channel 0410 data 404300
Lower bytes of the channel 0501 data 404301
Higher bytes of the channel 0501 data 404302
| |
Lower bytes of the channel 0510 data 404319
Higher bytes of the channel 0510 data 404320
Lower bytes of the channel 0601 data 404321
Higher bytes of the channel 0601 data 404322
| |
Lower bytes of the channel 0610 data 404339
Higher bytes of the channel 0610 data 404340
Lower bytes of the channel 0701 data 404341
Higher bytes of the channel 0701 data 404342
| |
Lower bytes of the channel 0710 data 404359
Higher bytes of the channel 0710 data 404360
Lower bytes of the channel 0801 data 404361
Higher bytes of the channel 0801 data 404362
| |
Lower bytes of the channel 0810 data 404379
Higher bytes of the channel 0810 data 404380
Lower bytes of the channel 0901 data 404381
Higher bytes of the channel 0901 data 404382
| |
Lower bytes of the channel 0910 data 404399
Higher bytes of the channel 0910 data 404400
4.5 Modbus Function and Register Assignments
