YOKOGAWA GX20 User Manual

App-15
IM 04L51B01-01EN
Appendix
1
2
3
4
5
App
Index
Note
• When the channel data is in the condition shown in the table below, the Er, Ov, or Bo status is
output to a report.
Data detection condition during report computation Status
Error Er
Over range data detection (including computation overflow of a math
channel)
Ov
Burnout Bo
Power failure Pw
Time change Cg
• The report output value of Ave, Max, Min, Sum, and Inst varies depending on the channel data
condition as shown in the table below.
Item Data Condition Report Output
Value
Max,
Min,
Inst
Error/When there are no valid data (Space)
+Over
1
Value indicated
for PlusOver in
the Extra Data
information
header section
–Over
1
Value indicated
for MinusOver
in the Extra
Data information
header section
Ave When there are no valid data (Space)
When the valid range is exceeded during computation
+Over
1
Value indicated
for PlusOver in
the Extra Data
information
header section
–Over
1
Value indicated
for MinusOver
in the Extra
Data information
header section
Sum/Ave When there are no valid data (Space)
When the valid range is exceeded during computation
1 +Over, –Over
+Over +Over range
Burnout
+Display over
–Over –Over range
Burnout
–Display over
Appendix 3 Text File Data Format
